Zebra MS4717 Fixed Mount Barcode Scanner

Short Description

    You need a perfect device to track and trace operations from a small restaurant to a high-volume airport ticket counter. Zebra MS4717 Fixed Mount Barcode Scanner is the ideal tool for reducing workflow errors and increasing productivity which features PRZM Intelligent Imaging technology that can instantly capture any 1D,2D barcodes for various wide ranges. Zebra MS4717 is specially designed for Restaurants, ATMs, Airline Check-in, Smart lockers, Ticket checkers, E-voting machines.

    Authorized Distributor of Zebra MS4717 Fixed Mount Barcode Scanner

Physical Characteristics

Dimensions 1.10 in. H x 1.89 in. L x 2.17 in. W
Weight 4.13 oz / 117 g
Input Voltage Range Maximum: 5 VDC +/- 10% @ 480 mA

Performance Characteristics

Image Sensor 1280 x 800 pixels
Imager Field of View 42° H x 28° V Nominal
Light Source Aiming Pattern: Circular 610nm Amber LED
Minimum Print Contrast 20% minimum reflective difference

User Environment

Operating Temperature -4° to 122° F /-20° to 50° C*
Storage Temperature -40° to 158° F /-40° to 70° C
Humidity Operating: 95% RH, non-condensing at 50°C Storage: 85% RH, non-condensing at 70°C
Drop Specification Designed to withstand multiple drops at 5.0 ft./1.5 m to concrete
Sealing IP54

Put the Zebra MS4717 Fixed Mount Barcode Scanner to Work in

Markets and Applications



Zebra MS4717 Fixed Mount Barcode Scanner
